Modbus Addressing Without Off-by-One Errors
Register notation, zero/one-based addressing, data type and byte order must be documented together.
Engineering decision first
Register notation, zero/one-based addressing, data type and byte order must be documented together. For an OEM machine builder, the correct choice is the one that reduces integration risk, keeps commissioning measurable and leaves maintenance engineers with a system they can diagnose.
What to document before selection
- Machine process, cycle time and operating modes
- Current controller / HMI / drive and complete model suffix
- Power, I/O, communication and mechanical interfaces
- Failure behavior, recovery and maintenance requirements
- Quantity, destination, documentation and certification needs
Recommended workflow
- Capture the installed or proposed architecture.
- Mark interfaces that cannot change without redesign.
- Separate mandatory functions from optional functions.
- Verify candidate hardware and software against those interfaces.
- Bench-test high-risk functions before machine commissioning.
- Prepare backup and rollback before changing a production machine.
Common failure modes
Most problems come from treating one headline specification as proof of compatibility. In practice, mounting, network behavior, firmware/software revision, cable pinout, scaling, state logic and commissioning procedures can all change the result.
FLEXEM selection boundary
Trompeter-Tech can recommend a FLEXEM product direction after reviewing the real machine information. Final ordering code and compatibility should be confirmed against the latest official FLEXEM documentation.
RFQ checklist
- Complete model / nameplate photo
- PLC or controller model
- Protocol and network details
- Machine application and motion/process requirement
- Quantity and destination
